Excavator Main Pump R210LC-7 R210LC-7A R220LC-7H Hydraulic Pump 31N6-10010 31N6-10051 31N6-10080 For Hyundai

Product Categories
GZ Yuexiang Engineering Machinery Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Excavator Main Pump R210LC-7 R210LC-7A R220LC-7H Hydraulic Pump 31N6-10010 31N6-10051 31N6-10080 For Hyundai

  • 1
  • 2
  • 3

Brand Name : Belparts

Model Number : R210LC-7 R210LC-7A R220LC-7H

Place of Origin : Guangdong, China

MOQ : 1 piece

Price : Negotiable price

Payment Terms : T/T, Paypal and Trade Assurance

Supply Ability : 1000pieces

Delivery Time : 1-5days

Packaging Details : Wooden packing

Product name : Excavator main pump

Machine model : R210LC-7 R210LC-7A R220LC-7H

Part number : 31N6-10010 31N6-10050 31N6-10051 31N6-10080 31N6-10020 31N6-10030

Brand : Belparts

Contact Now

Belparts excavator main pump R210LC-7 R210LC-7A R220LC-7H hydraulic pump 31N6-10010 31N6-10051 31N6-10080 for hyundai​


Quick Detail of Excavator Hydraulic Pump
Product Name:Excavator Hydraulic Pump
Brand:Belparts
Machine model:R210LC-7 R210LC-7A R220LC-7H
Packing Size:84*38*49
Part number: 31N6-10010 31N6-10050 31N6-10051 31N6-10080 31N6-10020 31N6-10030
Pressure:Standard, High Pressure

Specifiions Of Excavator Hydraulic Pump

Product Name Excavator Hydraulic Pump
Brand Belparts
Machine model R210LC-7 R210LC-7A R220LC-7H
Packing Size 84*38*49
Part number 31N6-10010 31N6-10050 31N6-10051 31N6-10080 31N6-10020 31N6-10030
Pressure Standard, High Pressure

# Part No Part Name Qty. Price request
* 31N6-10020 MAIN PUMP ASSY
SEE 4010		 1  
N*-1 XKAH-00612 MAIN PUMP UNIT 1  
111 XKAH-00562 SHAFT-DRIVING(F) 1  
113 XKAH-00563 SHAFT-DRIVING(R) 1  
114 XKAH-00565 COUPLING-SPLINE 1  
123 XKAH-00566 BEARING-ROLLER 2  
124 XKAH-00567 BEARING-NEEDLE 2  
127 XKAH-00568 SPACER-BEARING 4  
N141 XKAH-00569 CYLINDER-BLOCK 2  
N151 XKAH-00570 PISTON 18  
N152 XKAH-00571 SHOE 18  
153 XKAH-00572 PLATE-PUSH 2  
156 XKAH-00573 BUSH-SPHERICAL 2  
157 XKAH-00574 SPRING-CYLINDER 18  
158 XKAH-00575 SPACER 2  
211 XKAH-00576 PLATE-SHOE 2  
N212 XKAH-00577 PLATE-SWASH 2  
N214 XKAH-00578 BUSH-TILTING 2  
251 XKAH-00579 SUPPORT 2  
261 XKAH-00580 COVER-SEAL(F) 1  
271 XKAH-00247 CASING-PUMP 2  
312 XKAH-00581 BLOCK-VALVE 1  
N313 XKAH-00582 PLATE-VALVE(R) 1  
N314 XKAH-00583 PLATE-VALVE(L) 1  
401 XKAH-00584 BOLT-SOCKET 8  
406 XKAH-00210 BOLT-SOCKET 4  
466 XKAH-00136 PLUG-VP 2  
468 XKAH-00209 PLUG 3  
490 XKAH-00208 PLUG-PT 18  
N531 XKAH-00585 PIN-TILTING 2  
532 XKAH-00586 PISTON-SERVO 2  
534 XKAH-00587 STOPPER(L) 2  
535 XKAH-00588 STOPPER(S) 2  
N541 XKAH-00203 SEAT 4  
N543 XKAH-00201 STOPPER 1 2  
N544 XKAH-00200 STOPPER 2 2  
N545 XKAH-00199 BALL-STEEL 4  
N548 XKAH-00198 PIN-FEEDBACK 2  
K702 XKAH-00589 O-RING 2  
K710 XKAH-00590 O-RING 1  
K717 XKAH-00591 O-RING 4  
K724 XKAH-00194 O-RING 16  
K725 XKAH-00052 O-RING 4  
K728 XKAH-00193 O-RING 3  
K732 XKAH-00592 O-RING 2  
774 XKAH-00593 SEAL-OIL 1  
789 XKAH-00594 RING-BACK UP 2  
792 XKAH-00595 RING-BACK UP 2  
806 XKAH-00596 NUT-HEX 2  
808 XKAH-00188 NUT-HEX 2  
824 XKAH-00026 RING-SNAP 2  
885 XKAH-00597 PIN-VALVE PLATE 2  
886 XKAH-00185 PIN-SPRING 4  
901 XKAH-00598 BOLT-EYE 2  
953 XKAH-00599 SCREW-SET 2  
954 XKAH-00600 SCREW-ADJUST 2  
981 XKAH-00601 PLATE-NAME 1  
983 XKAH-00116 SCREW-RIVET 2  
N011 XKAH-00559 PISTON ASSY
SEE ILLUST		 2  
013 XKAH-00558 CYLINDER ASSY(RH)
SEE ILLUST		 1  
014 XKAH-00557 CYLINDER ASSY(LH)
SEE ILLUST		 1  
030 XKAH-00556 SWASH PLATE ASSY
SEE ILLUST		 2  
041 XKAH-00237 CHECK VALVE ASSY 1
SEE ILLUST		 2  
042 XKAH-00555 CHECK VALVE ASSY-2
SEE ILLUST		 2  
530 XKAH-00554 TILTING PIN ASSY
SEE ILLUST		 2  
*-2 @ FUEL INJECTION PIPE & NOZZLE
SEE 4020		 2  
*-3 @ FUEL INJECTION PIPE & NOZZLE
SEE 4030		 1  
*-4 @ FUEL INJECTION PIPE & NOZZLE
SEE 4040		 1  
N @ FUEL INJECTION PIPE & NOZZLE AR  
K XKAH-00613 PUMP BODY SEAL KIT
SEE ILLUST		 1  


Model
Nominal
displacement
(ml/r)		 Pressure(MPa) Speed(r/min)
Volumetric
efficiency
(≥%)		 h D L1 L
Weight
(kg)

Rated
Max
Optimum
speed
Speed
range
Rectabgle
Oval
Inlet
Outlet
CBQ-G520-*F** 20 25 28 1500-2500 800-3000 92 23 15 25 20 62.5 129 5.7
CBQ-G525-*F** 25 64.5 133 6.0
CBQ-G532-*F** 32 93 30 67 138 6.3
CBQ-G540-*F** 40 69.5 143 6.8
CBQ-G550-*F** 50 00
20		 25 25 73 150 7.3
CBQ-G563-*F* 63 77.5 159 8.0


Excavator Main Pump R210LC-7 R210LC-7A R220LC-7H Hydraulic Pump 31N6-10010 31N6-10051 31N6-10080 For Hyundai
